Mandibular Body

The mandibular body is the region of the mandible spanning from the canine teeth to the anterior border of the masseter, which is usually near the most-posterior molars. Mandibular body fractures can be classified as favorable or unfavorable based on the absence or presence of distracting muscular forces. These fractures are associated with injury to the inferior alveolar nerve.

Scrollable Stack Images

Images show a mandibular body fracture on the left and a mandibular angle fracture on the right. Both fractures demonstrate moderate displacement and step-off. The left mandibular body fracture is anteromedial to the submental foramen. The right mandibular angle fracture transverses the inferior alveolar canal.

Static 2D


Click to enlarge

Static 3D


Click to enlarge

Rotating 3D

Return to top

Axial image demonstrates a moderately displaced left mandibular body fracture.

Return to top

Coronal image demonstrates a moderately displaced left mandibular body fracture.

Return to top

A slightly more posterior coronal image demonstrates that the left mandibular body fracture is anteromedial to the left submental foramen.
